Lens rotation 1/2
No. | Reference | Description | Qty | Info |
|---|---|---|---|---|
| 1 | CV6672 | CHC screw 4×12 | 3 | |
| 2 | M24S14 | Cover with seals | 1 | |
| 3 | CH7021 | O-ring | 1 | |
| 4 | M40S18 | Fitted lens rotation shaft | 1 | |
| 5 | M15S15 | Centerer positioner | 1 | |
| 6 | CV6646 | CHC screw 3×20 | 1 | |
| 7 | N8221P | Wedge | 1 | |
| 8 | CI3029 | Onduflex washer | 1 | |
| 9 | CH7022 | Double-lip seal 15x6x5 | 2 | |
| 10 | CR1037 | Roller bearing 10×19×5 | 1 | |
| 11 | CH7045 | 14x22x4 double lip seal | 2 | |
| 12 | M40S52 | Equipped drive screw | 2 | |
| 13 | M40S17 | Lens clamp subset drive | 1 | |
| 14 | CH7024 | O-ring | 1 | |
| 15 | M40S16 | Lens clamp shaft | 1 | |
| 16 | CH7053 | V-Ring seal | 1 | |
| 17 | M2420H | Key | 1 | |
| 18 | M24S34 | Fully fitted cap | 2 | |
| 19 | CH7023 | O-ring | 2 | |
| 20 | CV6641 | CHC screw 3×8 | 6 | |
| CX4198 | SKF grease LGMT 2-02 (200g tube) | - |  | |
| CX4192 | Kluber grease 46-1200 GE (1kg box) | - | | |
| A | M40K20 | Secondary carriage drive kit | 1 |
